Wi-Fi Wireless Gas Boiler Thermostat with 868MHz RF Receiver
The TP608RFW is a smart wireless thermostat designed for gas boiler, electric heating systems. It combines Wi-Fi remote control with reliable
868MHz RF communication between the thermostat and receiver. With an open-air wireless range of over 150 metres, it provides flexible
installation and stable heating control for houses, apartments and commercial projects

Technical Data
| Features | Parameters |
| Application | Gas Boiler Heating |
| Frenquency | 868Mhz |
| Power | 2AA batteries and USB |
| Controlled Load | 3A |
| Mode | Programmable/Manaul Mode optional |
| Temperature Accuracy | +/-0.5℃ |
| Temperature Range | 5~60℃ |
| Programmable function | 5+1+1/7 days different/1(7days different)days programmable option |
| Button Lock Function | YES |
| Antifreeze Function | YES |
| Memory Function | YES |
| Sensor | NTC 10k 3977 |
| IP Class | IP20 |
| Dimension | Transmitter &Receiver:86x86x28mm |
Features
◆Wi-Fi APP Remote Control
Supports Tuya Smart and Smart Life APPs, allowing users to switch the heating system on or off, adjust temperatures and manage
operating modes remotely.
◆868MHz RF Wireless Communication
Reliable 868MHz communication connects the thermostat and receiver, with an open-air transmission distance of more than 150 metres.
◆Multiple Weekly Programming Options
Supports 5+1+1 programming, seven-day same scheduling and seven-day independent programming, with six temperature periods per day.
◆±0.5°C Precise Temperature Control
Maintains the room temperature within approximately 0.5°C of the selected setting for consistent comfort and efficient heating operation
◆Large Backlit LCD and Touch Buttons
The large LCD screen provides clear visibility in low-light conditions, while touch-sensitive buttons offer simple and intuitive operation.


FAQ
1.Are you Manufacturer?
Yes.We are original room thermostat manufacturer
2.Can I print my logo on thermostat?
Yes.MOQ500PCS
3.Can you design our local language display of your thermostat?
Yes.MOQ1000PCS
4.What’s the Warranty of your product?
2years after goods send out
5.How long can you ship the goods If I paid?
Samples within 3working days.Bulk order depends on.Normally 15-35days
6.Do I need a professional electrician to install a thermostat?
Yes, it is strongly recommended. Thermostats connect directly to mains voltage (95–240V AC) and heating loads. Incorrect wiring can cause
electrical shock, fire, or equipment damage. Always disconnect/isolate the power supply before installation and have a qualified electrician
perform the work.
7.Can one thermostat control multiple rooms?
Yes.If you order one thermostat and multi receivers.It will control on off at the same time.
