WiFi Fan Coil Unit thermostat

WiFi Fan Coil Unit thermostat

WiFi Fan Coil Unit thermostat
TP518 Series WiFi Fan Coil Thermostat with APP Remote Control for HVAC System
TP518 Series WiFi Fan Coil Thermostat with APP Remote Control for HVAC System
TP518 Series WiFi Fan Coil Thermostat with APP Remote Control for HVAC System
TP518 Series WiFi Fan Coil Thermostat with APP Remote Control for HVAC System
TP518 Series WiFi Fan Coil Thermostat with APP Remote Control for HVAC System
TP518 Series WiFi Fan Coil Thermostat with APP Remote Control for HVAC System
TP518 Series WiFi Fan Coil Thermostat with APP Remote Control for HVAC System
TP518 Series WiFi Fan Coil Thermostat with APP Remote Control for HVAC System
TP518 Series WiFi Fan Coil Thermostat with APP Remote Control for HVAC System
TP518 Series WiFi Fan Coil Thermostat with APP Remote Control for HVAC System

TP518 Series WiFi Fan Coil Thermostat with APP Remote Control for HVAC System

Application System:2pipe/4pipe Fan Coil Unit System

Model:TP518

●Valve control via 2-point(on/off output) or 0…10 V output

●Supports  with EC motor

●Non-Volatile memory to keep program settings and setpoints during a power outage

●7 days 4 perioods programmable (Optional)

●Child Lock

●Modbu RS485

●External Sensor  (Optional)

●Keycard  (Optional)

●WIFI Remote Control (Optional)

●BACnet Communication (Optional)

●Zigbee  (Optional)



  • Description

    WiFi Fan Coil Thermostat with APP Remote Control for HVAC System

    This WIFI smart fan coil thermostat is designed for modern HVAC applications, providing wireless control of fan coil units through  WIFI communication. Users can remotely manage room temperature, fan speed and HVAC modes through a mobile APP.Provide voice control via goolge and alexa.


     Technical Data

    FeaturesParameters
    Application2pipe/4Pipe Fan Coil Unit System
    PowerAC95- 240V/24V option, 50/ 60Hz
    Valve Control Signal On/Off or 0-10V
    ModeProgrammable/Manaul Mode optional
    Temperature Accuracy+/-0.5℃
    Control Temperature Range5~35℃
    Timmer function2perids available
    Fan3speed fan/EC motor 0-10V Fan
    Current Load
     Induction for fan: 3A, Resistive for fan: 5A
    Memory FunctionYES
    Housing PC anti fire
    IP Class IP20
    SensorNTC 10k 3977
    Installation Hole distance86box/60mmEurope standard round box
    Dimension86x86x14mm

      Features

    ◆WIFI wireless communication

    ◆Tuya /Smart life APP remote control

    ◆Voice Control via google and alexa

    ◆Compatible with Zigbee gateway

    ◆Fan coil unit control

    ◆Heating, cooling and ventilation modes

    ◆Fan speed adjustment (Auto/High/Medium/Low)

    ◆Energy-saving temperature management



      Application

    ◆Hotel HVAC System               ◆Apartments HVAC System                   ◆Hospital BMS System

    ◆School HVAC System            ◆Shopping Mall HVAC System             ◆Villa HVAC System


     FAQ

    1.Can this thermostat work with voice control?

    Yes.Google assistant and Amazon Alexa both ok

    2.Can your thermostat control 3-speed fan motors?

    Yes.

    3.Can your FCU thermostat control motorized valves?

    Yes.No matter 2wires or 3wires motorized valve.Our FCU thermostat could handle it.

    4.Can you print my brand on thermostat?

    Yes.MOQ500PCS free to print

    5.Can you develop based my requirements?

    Yes.ODM services MOQ1000PCS

    6.What’s the delivery for bulk order?

    Normally 10-30days.Depends on our production reply.
