Programmable Electric Heating Thermostat with Large TFT colorful

Touch Screen

This touch screen TFT colorful display thermostat designed for electric floor heating systems with a 16A relay.It is easy-to-read touch screen

thermostat with 6 programmable periods per day, anti-freeze protection, and child lock.This thermostat supports multiple languages, making

it ideal for OEM and European distributors.

 Technical Data

  Features

◆TFT Colorful Full Touch Screen

With 4inch TFT full colorful touch screen display.It is easily for you to enjoy the high technology

◆Program Mode

In this mode, the thermostat follows a programmed schedule. You can use a predefined schedule or create your own custom schedule with

up to 6 temperature changes per day. Schedules can be set for individual

◆Multi Languages option

We provide EN/PL/RU/DE/SI now.It is easily to customize your local language

◆Different external sensors option

Our thermostat available to connect with Ntc 10K,12K,15Ksensor.You can change in Menu select Sensor value selection

◆Anti Free Mode

This mode prevents the temperature from dropping below a user-defined minimum (typically between 2°Cand 10°C). If the ambient temperature

falls below this threshold, the heating system will activate to maintain the minimum temperature, protecting against freezing.

◆Holiday Mode

Designed for periods of absence, this mode lowers the temperature to an energy-saving level until a preset return date. The heating system will

then resume normal operation according to the programmed schedule.

◆Open Window Function

This function designed to energy saving.When detect room temperature drop rabidly.This function will active to prevent energy wast.

  Application

◆Hotel underfloor heating system  ◆Villa hydronic heating control  ◆Building heating control system

◆Apartment heating control system  ◆Smart home heating control

 FAQ

1.Can I temporarily override the programmed temperature?

Yes, the "temporary override" function lets you adjust the temperature during a program period without permanently changing the schedule.

The thermostat will hold your manual setting only until the next scheduled period begins, then automatically resume the preset program.

2.Can you print my brand on your thermostat?

Yes.MOQ500PCS we could print your logo free on thermostat

3.Can you customize our language manual?

Yes.MOQ1000PCS

4.Can you ODM UI for us?

Yes.We can customize.Our R&D team work in this line 20years

5.How long you can send out goods?

Samples normally within 3working days.Bulk order 15-35days

6.What is the difference between Manual Mode and Program Mode?

Manual Mode: The thermostat maintains one fixed temperature 24/7 until you manually change it — like a traditional thermostat.

Program Mode: The thermostat automatically follows your pre-set weekly schedule, changing temperatures at designated times throughout each day.

7.How does ECO mode save energy?

ECO mode runs the system at a reduced set temperature (typically 16°C factory default, configurable from 5–30°C). It is ideal for when you are asleep,

away at work, or on vacation — maintaining a minimum safe temperature while minimizing energy consumption. The temperature can be adjusted via

the thermostat's configuration menu.
