Application: Water Underfloor Heating System/Hydronic Underfloor Heating System
Model: WIFI version model
TP528WHPW-B（Black / TP528WHPW-W（White)
TP528WHPW-B-24V（Black)/ TP528WHPW-W-24V（White)
NO WIFI version model
TP528WHP-B（Black)/ TP528WHP-W（White)
TP528WHP-B-24V（Black) / TP528WHP-W-24V（White
*UL 94V0 PC anti fire housing to make sure saftely
*Large VA ink LCD is comfort to see even during dark night
*Weekly program each day 6periods energy saving for you
*China TOP1 relay to make sure thermostat 100,000 lifetime
*Data memory even power off
*Control accurancy 0.5°C,Measure Temperature accurancy:0.1°C
*WIFI/ZIGBEE/MODBUS flexiable communication way for you select
*Tuya/Smart life app to control your thermostat anywhere
*White/Black/ODM color
*CE/ROHS/UKCA/FCC/REACH approved
This 7 days programmable thermostat is a thermostat which is suitable electric underfloor heating system.Appilcation system including
Heating mat,Heating cable,infared heating panel,heater etc.It has two sensors to energy saving.Normally it has weely program function
each day 6periods to setting your desire room temp.Child clock to protect thermostat do not change easily.WIFI app control you could
change your temp anywhere.Voice control via google alexa,Amazon echo.Yandex alice etc.Modbus/Zigbee function also option
Technical Data
| Features | Parameters |
|---|---|
| Application | Underfloor Heating System/Water Heating System/Gas Boiler Heating System |
| Power |
AC95- 240V/24V option, 50/ 60Hz
|
| Controlled Load |
water heater 5A/electric heater 16A
|
| Mode | Programmable/Manaul Mode optional |
| Temperature Accuracy | +/-0.5℃ |
| Temperature Range | 5~60℃ |
| Programmable function | 5+1+1 Weekly Program |
| Button Lock Function | YES |
| Antifreeze Function | YES |
| Memory Function | YES |
| Temperature Sensor | Two Sensors(UHP model)/One senor(WHP model,GCmodel) |
| External Floor Sensor Length | 2.5meters |
| Sensor | NTC 10k 3977 |
| Phone Application | Tuya/Smart Life |
| Voice Assistant | Google Home/Amazon Alexa (only Wi-Fi models support) |
| Installation Hole distance | 86box/60mmEurope standard round box |
| Dimension | 86x86x40mm |
Wiring Diagram
